THE ROOTS

Distributed Audio System Processor

256 x 256 networked audio channels (Q-LAN / AES67)

Configurable onboard I/O via 8 open Q-SYS IO Cards slots

64 x AEC processors

up to 128 x 128 Dante audio channels (8 x 8 included)

Full-featured Q-SYS Control engine (with optional feature license)

16 x 16 GPIO

Build for Q-SYS – Simple drag-and-drop integration into your Q-SYS design, enabling network routing, advanced processing and control.

Legacy of power redefined – These network amplifiers are built with a 5th generation high-efficiency, Class-D hybrid powertrain design built upon the dependable PL380 PowerLight™ amplifier platform.

Flexible & efficient channel power distribution – CX-Q Series network amplifiers feature FlexAmp™ and FAST (Flexible Amplifier Summing Technology™), which combine to provide extreme flexibility in output deployment.

Routable input options  – Eight channels of mic/line inputs (with +12 V phantom power) for additional on-ramps into Q-SYS.

The NS-10 is an 8-ohm two-way loudspeaker with a 10.4-litre sealed cabinet measuring 382 × 215 × 199 millimetres (15.0 × 8.5 × 7.8 in) and weighing 6 kilograms (13.2 lb).[5][4] Its 2.5 cm (0.98 in) particle-board cabinet has a wood veneer skin with seven black finishing layers. The domestic version of the speaker was vertically oriented, and came factory fitted with a grille.[6][5]

Its two drivers are a 180 mm paper woofer and a 35 mm soft-domed tweeter.[5][4] The woofer's diaphragm, weighing 3.7 g, is manufactured from a flat sheet of pressed pulp paper. Unconventionally, it is formed into conical shape not through moulding or pressure, but by curling and then gluing the two ends together.[5] Against the black finish of the cabinet, the white bass/mid driver cone is a distinctive and iconic feature of the product.[6][5]

The network is second-order passive, crossing over at 2 kHz. The frequency range is quoted from 60 Hz to 20 kHz, and rated power handling is 25–50 W.[5][4] The early version of the speaker has press-down type input terminals; later models had screw terminals.

Custom built sealed 1.06 Cubic foot MDF cabinet with 1- 10" Passive Reference Subwoofer

2-way acoustic-suspension speaker system

9 cm cone woofer & 2.5 cm tweeter

2-way acoustic-suspension speaker system

2- 9 cm cone woofers & 1- 2.5 cm tweeter
